| 型号 |
流量 m³/h |
扬程 m |
效率 % |
汽蚀余量 m |
进口×出口 mm |
转速 r/min |
电机功率 kw |
整机质量 kg |
| QFC25-20-125-2 | 1.7 | 20 | 28 | 3 | 25 × 20 | 2900 | 1.1 | 80 |
| QFC25-20-160-2 | 1.7 | 32 | 29 | 3 | 25 × 20 | 2900 | 1.5 | 90 |
| QFC32-25-125-2 | 3.6 | 20 | 38 | 3 | 32 × 25 | 2900 | 1.5 | 98 |
| QFC32-25-160-2 | 3.6 | 32 | 39 | 3 | 32 × 25 | 2900 | 2.2 | 116 |
| QFC40-25-125-2 | 6.3 | 20 | 38 | 3 | 40 × 25 | 2900 | 1.5 | 98 |
| QFC40-25-160-2 | 6.3 | 32 | 31 | 3 | 40 × 25 | 2900 | 2.2 | 100 |
| QFC40-25-200-2 | 6.3 | 50 | 23 | 3 | 40 × 25 | 2900 | 5.5 | 170 |
| QFC40-32-250-2 | 6.3 | 80 | 24 | 5 | 40 × 32 | 2900 | 11 | 255 |
| QFC50-32-125-2 | 12.5 | 20 | 52 | 3.2 | 50 × 32 | 2900 | 2.2 | 110 |
| QFC50-32-160-2 | 12.5 | 32 | 47 | 3.2 | 50 × 32 | 2900 | 4 | 135 |
| QFC50-32-200-2 | 12.5 | 50 | 40 | 3.2 | 50 × 32 | 2900 | 7.5 | 180 |
| QFC50-32-250-2 | 12.5 | 80 | 34 | 5 | 50 × 32 | 2900 | 11 | 255 |
| QFC65-50-125-2 | 25 | 20 | 61 | 3.5 | 65 × 50 | 2900 | 3 | 135 |
| QFC65-50-160-2 | 25 | 32 | 56 | 3.5 | 65 × 50 | 2900 | 5.5 | 155 |
| QFC65-40-200-2 | 25 | 50 | 51 | 3.5 | 65 × 40 | 2900 | 11 | 210 |
| QFC65-40-250-2 | 25 | 80 | 48 | 3.5 | 65 × 40 | 2900 | 18.5 | 360 |
| QFC80-65-125-2 | 50 | 20 | 65 | 4 | 80 × 65 | 2900 | 5.5 | 195 |
| QFC80-65-160-2 | 50 | 32 | 64 | 4 | 80 × 65 | 2900 | 11 | 228 |
| QFC80-50-200-2 | 50 | 50 | 63 | 4 | 80 × 50 | 2900 | 15 | 250 |
| QFC80-50-250-2 | 50 | 80 | 56 | 4.5 | 80 × 50 | 2900 | 30 | 480 |
| QFC100-80-125-2 | 100 | 20 | 65 | 4.5 | 100 × 80 | 2900 | 11 | 245 |
| QFC100-80-160-2 | 100 | 32 | 70 | 5 | 100 × 80 | 2900 | 15 | 250 |
| QFC100-65-200-2 | 100 | 50 | 68 | 5 | 100 × 65 | 2900 | 30 | 480 |
| QFC100-65-250-2 | 100 | 80 | 65 | 5 | 100 × 65 | 2900 | 45 | 880 |
| QFC125-100-160-2 | 160 | 32 | 68 | 5 | 125 × 100 | 2900 | 30 | 630 |
| QFC125-100-200-2 | 200 | 50 | 67 | 6 | 125 × 100 | 2900 | 55 | 980 |
| QFC125-100-250-2 | 200 | 80 | 62 | 6 | 125 × 100 | 2900 | 75 | 1100 |
型号
流量
m³/h
扬程
m
效率
%
汽蚀余量
m
进口×出口
mm
转速
r/min
电机功率
kw
整机质量
kg
QFC32-25-125-4
1.8
5
38
3
32 × 25
1450
0.55
QFC32-25-160-4
1.8
8
39
3
32 × 25
1450
0.55
QFC40-25-160-4
4
8
31
3
40 × 25
1450
0.55
QFC40-25-200-4
4
12
23
3
40 × 25
1450
1.1
QFC40-32-250-4
4
20
24
5
40 × 32
1450
1.5
QFC50-32-125-4
6.3
5
52
3.2
50 × 32
1450
0.55
QFC50-32-160-4
6.3
8
47
3.2
50 × 32
1450
0.55
QFC50-32-200-4
6.3
12.5
40
3.2
50 × 32
1450
1.1
QFC50-32-250-4
6.3
20
34
5
50 × 32
1450
1.5
QFC65-50-125-4
12.5
5
61
3.5
65 × 50
1450
0.55
QFC65-50-160-4
12.5
8
56
3.5
65 × 50
1450
1.1
QFC65-40-200-4
12.5
12.5
51
3.5
65 × 40
1450
1.5
QFC65-40-250-4
12.5
20
48
3.5
65 × 40
1450
3
QFC80-65-125-4
25
5
65
4
80 × 65
1450
1.1
QFC80-65-160-4
25
8
64
4
80 × 65
1450
1.5
QFC80-50-200-4
25
12.5
63
4
80 × 50
1450
2.2
QFC80-50-250-4
25
20
56
4.5
80 × 50
1450
3
QFC100-80-125-4
50
5
65
4.5
100 × 80
1450
1.5
QFC100-80-160-4
50
8
70
5
100 × 80
1450
3
QFC100-65-200-4
50
12.5
68
5
100 × 65
1450
5.5
QFC100-65-250-4
50
20
65
5
100 × 65
1450
7.5
QFC125-100-160-4
80
8
64
5
125 × 100
1450
5.5
QFC125-100-200-4
100
12.5
65
6
125 × 100
1450
11
QFC125-100-250-4
100
20
68
6
125 × 100
1450
15
QFC150-125-250-4
200
20
65
7
150 × 125
1450
22
520
QFC150-125-315-4
200
32
63
7
150 × 125
1450
45
730
QFC150-125-400-4
200
50
62
7
150 × 125
1450
75
1200
QFC200-150-250-4
400
20
63
7.5
200 × 150
1450
55
730
QFC200-150-315-4
400
32
64
7.5
200 × 150
1450
75
1200
QFC200-150-400-4
400
50
62
7.5
200 × 150
1450
110
1450
